RISE BEYOND

A NEW STANDARD IN LIGHTWEIGHT EBIKES

Rise shook up the lightweight e-MTB world on its launch with its “more bike, less E” philosophy. Simply the most natural feeling ebike on the market, bringing riders closer to the trail and shattering expectations about how an ebike should ride.

SUPERCHARGE YOU

Rider Synergy means that when you pedal harder, RISE responds instantly, multiplying your efforts and shooting you forward just as if you were fitter than ever. The instantaneous, lag-free, power and the way that it is delivered, means that it feels totally natural to be this strong and you just concentrate on the fun of riding.

IT IS ALL ABOUT THE RIDE

Obsessively removing weight means Rise is one of the lightest ebikes in this sector. Rise rewrites the rulebook on ebike handling, floating, popping, manualling, and slicing through the corners as it disappears into the distance.



The reactive, exciting handling owes much to the lack of inertia, but frame rigidity is vital too. Our SBS system helps give a lighter, stiffer frame, meaning we can tune the rigidity much as we do for our non-electric bikes.

CONFIGURE RISE WITH THE BIGGER 540WH BATTERY, OR THE LIGHTER 360WH BATTERY, DEPENDING ON THE LENGTH OF YOUR TYPICAL RIDE.

The beauty of our Modular Battery Solution is that you can add the Range Extender for the longest rides or leave that extra weight at home when you don’t need it.



SPECIFICATIONS

FRAMES

FRAME

Orbea Rise Evo OMR 2023, 140mm travel, 29" wheels, Concentric Boost 12x148

SHOCK

Fox Float DPS Performance 3-Position Evol custom tune 210x55mm

FORK

Fox 34 Float Performance 140 3-Position QR15x110

HEADSET

Alloy 1-1/2", Black Oxidated Bearing

DRIVETRAIN

CHAINRING

e*thirteen e*spec Direct Mount 32T Boost

CRANK

Shimano Steps EM600

SHIFTERS

Shimano SLX M7100 I-Spec EV

CASSETTE

Shimano CS-M7100 10-51t 12-Speed

REAR DERAILLEUR

Shimano SLX M7100 SGS Shadow Plus

CHAIN

Shimano M6100

CHAINGUIDE

Orbea Rise chainguide

COCKPIT

HANDLEBAR

OC Mountain Control MC21 Alu SL, Rise20, Width 800

STEM

OC Mountain Control MC20, 0º

BRAKES

BRAKES

Shimano M6100 Hydraulic Disc

BRAKES CONFIGURATION



WHEELS

WHEELS

Race Face AR 30c Tubeless Ready

TYRES

Maxxis Dissector 2.40" 60 TPI 3CMaxxTerra Exo TLR

TYRES

Maxxis Rekon 2.40" 120 TPI 3CMaxxTerra Exo+ TLR

COMPONENTS

SEATPOST

OC Mountain Control MC20, 31.6mm, Dropper

SEATPOST LEVER

Shimano SL-MT500 I-Spec EV

SADDLE

Fizik Taiga S-alloy rail

EBIKE

MOTOR

Shimano EP801-RS

BATTERY

Orbea Internal 360Wh (Optional 540Wh)

RANGE EXTENDER

N/A

DISPLAY

N/A

CHARGER

Orbea 2.Generation eBike Smart charger 42V/2-4A

REMOTE

EN600-L

SKU 815303
Brand Orbea
Shipping Weight 20.0000kg
Shipping Width 1.400m
Shipping Height 0.500m
Shipping Length 0.800m
Shipping Cubic 0.560000000m3
